Frameset |
|
Sizes |
13, 16, 18, 19.5, 21, 22.5, 24" |
|
Frame |
Alpha Black Aluminum w/semi-integrated head tube, formed down tube w/integrated gusset, formed top tube, monostay seatstay, forged dropouts w/rack and fender mounts, replaceable derailleur hanger |
|
Front Suspension |
Suntour SF9-XCR RL w/coil spring, preload, remote lockout, 100mm |
|
Wheels |
|
Wheels |
Shimano M495-L centerlock hubs; Bontrager Ranger rims |
|
Tires |
Bontrager Jones XR, 26x2.25" front, 26x2.20" rear |
|
Drivetrain |
|
Shifters |
Shimano Deore |
|
Front Derailleur |
Shimano Deore |
|
Rear Derailleur |
Shimano SLX Shadow |
|
Crank |
Shimano M442 44/32/22 |
|
Cassette |
SRAM PG950 11-34, 9 speed |
|
Pedals |
Wellgo alloy platform |
|
Components |
|
Saddle |
Bontrager Race Lux |
|
Seat Post |
Bontrager SSR, 31.6mm, 20mm offset |
|
Handlebars |
Bontrager Approved Riser, 25mm rise |
|
Stem |
Bontrager SSR, 31.8mm, 10 degree |
|
Headset |
VP-A42E, 1-1/8" semi-integrated, sealed |
|
Brakeset |
Shimano M486, hydraulic disc |
